Green Pin P-6011 Polar Heavy Duty Bow Shackle (Flat Nut)

The Green Pin P-6011 Polar Heavy Duty Bow Shackle is an oversized, cold-rated bow shackle designed for extreme heavy lifts in Arctic and sub-zero environments. The heavy-duty cross section provides higher WLL than standard sizes, while the Polar-grade steel maintains impact toughness at extreme low temperatures.

Key Features

• Heavy-duty cross section for extreme working load limits
• Polar-rated steel with Charpy impact verification for sub-zero use
• Flat nut pin for secure closure
• Forged alloy steel, hot-dip galvanized
• Individually proof tested at 2x WLL with certificate

Common Applications

• Arctic offshore heavy lift operations
• Northern construction and infrastructure projects
• Cold-climate crane and rigging operations
• Heavy lifts in sub-zero environments

Why Green Pin?

The P-6011 combines heavy-duty capacity with verified cold-temperature performance — the ultimate bow shackle for Arctic and sub-zero heavy lifting. Van Beest's individual proof testing and Charpy verification ensure reliable performance when conditions are harshest.

Standards & Compliance

Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.

Governing Standards

• ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
• ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
• ASME B30.10 — hooks
• OSHA 1910.184 and 1926.251 — general industry and construction sling safety
• WSTDA WS-2 and RS-1 — web and round sling design
• 49 CFR 393.102 to 393.130 — DOT cargo tie-down
• NACM — welded steel chain grade specs

Inspection & Safety

Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.

WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
