Green Pin CRC Clevis Grab Hook EN 1677-1 Grade 8

The Green Pin CRC Clevis Grab Hook is a Grade 8 clevis-mounted grab hook designed for chain shortening and cargo securement. The narrow hook throat grabs individual chain links to adjust sling length on the fly, while the clevis connection pivots freely for optimal load alignment.

Key Features

• Clevis connection for direct chain attachment with pivot action
• Narrow throat designed to grab individual chain links
• Grade 8 alloy steel for full chain system capacity
• EN 1677-1 compliant
• Individually proof tested with certificate
• Compact design minimizes sling assembly weight

Common Applications

• Chain sling length adjustment (shortening)
• Cargo lashing and securement
• Rigging with adjustable chain legs
• Transport and flatbed tie-down systems

Why Green Pin?

Green Pin grab hooks are trusted worldwide for chain shortening and load securement. Every hook carries Van Beest's individual proof test certification, giving riggers and drivers confidence in every connection.

Standards & Compliance

Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.

Governing Standards

• ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
• ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
• ASME B30.10 — hooks
• OSHA 1910.184 and 1926.251 — general industry and construction sling safety
• WSTDA WS-2 and RS-1 — web and round sling design
• 49 CFR 393.102 to 393.130 — DOT cargo tie-down
• NACM — welded steel chain grade specs

Inspection & Safety

Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.

WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
