Green Pin CO Omega Link Grade 8 EN 1677-1

The Green Pin CO Omega Link Grade 8 is an oblong connecting link designed to join chain components in Grade 8 chain sling assemblies. Compliant with EN 1677-1, this omega-shaped link provides a strong, compact connection point that maintains the chain system's full rated capacity.

Key Features

• Grade 8 alloy steel for matched capacity with Grade 8 chain
• Omega (oblong) shape for compact, efficient connections
• Flash-butt welded construction
• Individually proof tested at 2.5× WLL
• EN 1677-1 compliant
• Available in sizes to match standard chain diameters

Common Applications

• Connecting chain legs to master links in sling assemblies
• Joining chain to hooks and other end fittings
• Grade 8 chain sling fabrication
• Overhead lifting and rigging

Why Green Pin?

Green Pin connecting links are manufactured with the same precision welding and individual proof testing as all Van Beest chain components — ensuring consistent, traceable quality throughout the entire sling assembly.

Standards & Compliance

Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.

Governing Standards

• ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
• ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
• ASME B30.10 — hooks
• OSHA 1910.184 and 1926.251 — general industry and construction sling safety
• WSTDA WS-2 and RS-1 — web and round sling design
• 49 CFR 393.102 to 393.130 — DOT cargo tie-down
• NACM — welded steel chain grade specs

Inspection & Safety

Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.

WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
