Overview
Solid 2"-thick DICA TuffTrak XL access mats replace heavy, soggy swamp mats, CLTs, and other wood access and temporary roadway mats — ideal for extra-wide temporary access roadways. Mats are 13'6" x 6'8", support wheeled and tracked equipment up to 150 tons, and flex to conform to the ground when loaded yet won't crack, break or fail. Engineered HWM polyethylene won't rot, splinter, degrade, or absorb water or contaminants.
Features
- Load bearing capacity up to 150 tons (wheeled and tracked equipment).
- 838 lbs per mat; 13'6" x 6'8" — nearly 90 sq ft of usable area.
- Rugged nub chevron tread pattern on one side, micro traction on the other.
- Deploy butted end-to-end, or link with TTXL-C spring steel connectors on undulating or sloped terrain.
- Chemically inert — eliminates cross-site contamination.
- Transport 50 access mats per truckload.
Applications
Hydraulic mobile cranes, all-terrain cranes, self-erecting tower cranes, concrete pump trucks, larger aerial lifts, digger derricks and more. Typical use: heavy construction, rig pads, fracking, oil & gas, film work, low compaction, tree root protection, biosolids distribution, solar farms, wind farms, and electrical transmission.
Available Sizes & Configurations
TTXL mat (black only) plus the TTXL-C spring steel connector, sold separately. See the Technical Specifications tab below.
Lead Time
Standard delivery 4–6 weeks; ships freight (forklift needed; lift gate can be pre-ordered for a fee). Confirmed at quote.
How to Order
Click "Request a Quote" to get current pricing, availability, and freight to your location. Our team confirms specifications with the manufacturer before order placement.
Have technical questions? Chat with our AI rigging specialist (bottom-right) or email sales@slingcenter.com.
Specifications — Mat & Connector
| Model | Item | Thickness(in) | W x L(in) | Weight(lbs) | Load Capacity | Color |
|---|---|---|---|---|---|---|
| TTXL | Access Mat | 2 | 161 x 80 | 838 | 150 tons | Black |
| TTXL-C | Spring Steel Connector | 0.2 | 1.5 x 10.25 | 0.75 | — | Black |
Specifications sourced directly from DICA manufacturer catalog. Engineered HWM polyethylene · Black only · 50 mats per truckload · Standard delivery 4–6 weeks.
Standards & Compliance
Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.
Governing Standards
- ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
- ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
- ASME B30.10 — hooks
- OSHA 1910.184 and 1926.251 — general industry and construction sling safety
- WSTDA WS-2 and RS-1 — web and round sling design
- 49 CFR 393.102 to 393.130 — DOT cargo tie-down
- NACM — welded steel chain grade specs
Inspection & Safety
Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.
WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
