Overview
DICA SafetyTech Special Duty Cavity Pads are engineered for outriggers requiring a recessed pad surface that contains the stabilizer foot. The inverted beveled-edge guard reduces the potential of an outrigger-foot escape — the completely solid pad design eliminates metal fasteners, providing an unbreakable foot guard. Cavity Pad Plus models nest together for compact stored height. Available with 3-sided or 4-sided lip configurations.
Manufactured by DICA, USA-made and 100% Guaranteed Unbreakable.
Features
- Cavity Pad Plus: 4-sided inverted beveled-edge guard, stackable nesting design
- Cavity Pad (DC2020/DC2424): 3-sided or 4-sided lip, 1.5" total thickness
- Solid construction — no metal fasteners
- Working Load Limit 45,000 – 60,000 lbs depending on size
- 200 psi crush rating
- Patented TuffGrip handles — 100% Guaranteed Unbreakable
- 100% Guaranteed Unbreakable by DICA
- Made in USA
Standards & Compliance
- ASME B30.5 compliant for outrigger pad use
- 100% Guaranteed Unbreakable by DICA
- Made in USA
Available Sizes & Configurations
See the Technical Specifications tab below for cavity configuration, size, and capacity matrix.
Lead Time
Cavity Pad Plus (DCP1818-S4, DCP2424-S4) and DC2424-1.5: typically 1 business day. DC2020 variants: typically 15 business days. Confirmed at quote.
How to Order
Click "Request a Quote" to get current pricing, availability, and freight to your location. Our team confirms specifications with the manufacturer before order placement.
Have technical questions? Chat with our AI rigging specialist (bottom-right) or email sales@slingcenter.com.
Specifications — SafetyTech Special Duty Cavity Pads
| Model | Type | Size (W x L x H)(in) | Approx Area(sq ft) | Weight(lbs) | Working Load Limit(lbs) | Crush Rating(psi) |
|---|---|---|---|---|---|---|
| DCP1818-S4 | Cavity Pad Plus | 18 x 18 x 1 | 2 | 13 | 45,000 | 200 |
| DCP2424-S4 | Cavity Pad Plus | 24 x 24 x 1 | 4 | 23 | 60,000 | 200 |
| DC2020-1.5-A | Cavity Pad (4-sided) | 20 x 20 x 1.5 | 3 | 14 | 50,000 | 200 |
| DC2020-1.5L-O | Cavity Pad (3-sided) | 20 x 20 x 1.5 | 3 | 14 | 50,000 | 200 |
| DC2424-1.5 | Cavity Pad (4-sided) | 24 x 24 x 1.5 | 4 | 20 | 60,000 | 200 |
Cavity Pad Plus models stack and nest for compact storage. Standards: ASME B30.5 · 100% Guaranteed Unbreakable · Made in USA. Lead time: 1 business day for Cavity Pad Plus; 15 business days for DC2020 variants.
Standards & Compliance
Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.
Governing Standards
- ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
- ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
- ASME B30.10 — hooks
- OSHA 1910.184 and 1926.251 — general industry and construction sling safety
- WSTDA WS-2 and RS-1 — web and round sling design
- 49 CFR 393.102 to 393.130 — DOT cargo tie-down
- NACM — welded steel chain grade specs
Inspection & Safety
Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.
WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
Chat with our AI rigging specialist
Fastest: click the Ask SlingCenter chat widget in the bottom-right of any page. Our AI specialist is available 24/7 and trained on ASME B30.9, B30.26, OSHA rigging standards, and our full catalog. It can help you size a sling, pick the right shackle, explain inspection criteria, and look up your order.
Prefer to email?
Send to: sales@slingcenter.com
Include:
- What you are lifting (shape, material, fragility)
- Load weight (lb)
- Length / reach needed
- Pick points — smooth lugs, sharp edges, or a hook?
- Environment — indoor, outdoor, heat, saltwater, chemicals?
- Quantity and timeline
- Your phone number if you want a callback
Response: AI chat instant. Email within 1 business day. Urgent orders same-day on standard configurations.
Order Sheet — 5 variants
Search below or click column headers to sort. Add any quantity per row to your cart.
| Option ▴▾ | SKU ▴▾ | Price ▴▾ | Stock | Qty | Add |
|---|---|---|---|---|---|
| Cavity Pad Plus 18" x 18" x 1" | DCP1818-S4 | $158.55 | ✓ In Stock | ||
| Cavity Pad Plus 24" x 24" x 1" | DCP2424-S4 | $215.25 | ✓ In Stock | ||
| Cavity Pad 20" x 20" x 1.5" (4-sided lip) | DC2020-1.5-A | $203.70 | ✓ In Stock | ||
| Cavity Pad 20" x 20" x 1.5" (3-sided lip) | DC2020-1.5L-O | $225.75 | ✓ In Stock | ||
| Cavity Pad 24" x 24" x 1.5" | DC2424-1.5 | $257.25 | ✓ In Stock |
Bulk order? Email sales@slingcenter.com with your list — we'll build a single quote.
