Specifications — All 4 Models
| Model | Diameter(in) | Thickness(in) | Approx Area(sq ft) | Weight(lbs) | Working Load Limit(lbs) | Crush Rating(psi) |
|---|---|---|---|---|---|---|
| DR36-3 | 36 | 3 | 7 | 102 | 130,000 | 600 |
| DR42-3 | 42 | 3 | 9.5 | 138 | 150,000 | 600 |
| DR48-3 | 48 | 3 | 12.5 | 180 | 170,000 | 600 |
| DR60-3 | 60 | 3 | 19.5 | 285 | 210,000 | 600 |
Dimensions sourced directly from DICA manufacturer catalog. Standards: ASME B30.5 · 100% Guaranteed Unbreakable · Made in USA. 9 business day standard lead time.
DICA SafetyTech® Super Duty outrigger pads (3" thick) spread outrigger and stabilizer loads over a larger ground area to reduce ground-bearing pressure. Best suited to larger boom trucks, concrete pumps and mobile cranes where outrigger loads are highest. Models in this listing: DR36-3, DR42-3, DR48-3, DR60-3. Listed under DICA's own model numbers.
Specifications - Super Duty, crush rating 600 psi
| DICA Model | W x L x H | Shape / Color | Approx. Area (sq ft) | Weight (lb) | Working Load Limit (lb) | Crush Rating (psi) |
|---|---|---|---|---|---|---|
| DR36-3 | 36 diameter x 3 in | Round | 7 | 102 | 130,000 | 600 |
| DR42-3 | 42 diameter x 3 in | Round | 9.5 | 138 | 150,000 | 600 |
| DR48-3 | 48 diameter x 3 in | Round | 12.5 | 180 | 170,000 | 600 |
| DR60-3 | 60 diameter x 3 in | Round | 19.5 | 285 | 210,000 | 600 |
Crush Rating - the maximum allowable pressure. Working Load Limit - the maximum allowable load based on the application. Specifications from the DICA SafetyTech product sheet (rev. 3.26).
Features
- Made in the USA by DICA, family owned since 1988.
- Guaranteed unbreakable engineered thermoplastic - will not absorb water, splinter, rot or crack from pressure, UV, insects or extreme temperatures.
- ASME B30.5 compliant and designed to distribute load and reduce ground-bearing pressure.
- TuffGrip® handles - guaranteed unbreakable and sized for proper lifting with a low trip profile.
- Lighter and easier to set up, clean and store than wood cribbing or timber pads.
Choosing the right pad
- Medium Duty - 1" and 1.5" thick, 200 psi crush rating.
- Heavy Duty - 2" thick, 500 psi crush rating.
- Super Duty - 3" thick, 600 psi crush rating.
Size the pad to your outrigger load and the ground you are setting up on. Outrigger pads must be placed on a flat, level surface capable of supporting the imposed load. Not sure which pad fits your equipment? Send us your outrigger load and ground conditions and we will help you choose.
Business accounts with Net 30 terms available.
Safety & Standards
Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.
Governing Standards
- ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
- ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
- ASME B30.10 — hooks
- OSHA 1910.184 and 1926.251 — general industry and construction sling safety
- WSTDA WS-2 and RS-1 — web and round sling design
- 49 CFR 393.102 to 393.130 — DOT cargo tie-down
- NACM — welded steel chain grade specs
Inspection & Safety
Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.
WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
Order Sheet — 4 variants
Search below or click column headers to sort. Add any quantity per row to your cart.
| Option ▴▾ | SKU ▴▾ | Price ▴▾ | Stock | Qty | Add |
|---|---|---|---|---|---|
| 36" diameter x 3" | DR36-3 | $788.00 | ✓ In Stock | ||
| 42" diameter x 3" | DR42-3 | $1,117.00 | ✓ In Stock | ||
| 48" diameter x 3" | DR48-3 | $1,253.00 | ✓ In Stock | ||
| 60" diameter x 3" | DR60-3 | $1,882.00 | ✓ In Stock |
Bulk order? Email sales@slingcenter.com with your list — we'll build a single quote.
Chat with our AI rigging specialist
Fastest: click the Ask SlingCenter chat widget in the bottom-right of any page. Our AI specialist is available 24/7 and trained on ASME B30.9, B30.26, OSHA rigging standards, and our full catalog. It can help you size a sling, pick the right shackle, explain inspection criteria, and look up your order.
Prefer to email?
Send to: sales@slingcenter.com
Include:
- What you are lifting (shape, material, fragility)
- Load weight (lb)
- Length / reach needed
- Pick points — smooth lugs, sharp edges, or a hook?
- Environment — indoor, outdoor, heat, saltwater, chemicals?
- Quantity and timeline
- Your phone number if you want a callback
Response: AI chat instant. Email within 1 business day. Urgent orders same-day on standard configurations.
