Crosby SS-125M Stainless Steel Swivel Hoist Ring (Metric Threads)

The Crosby SS-125M is a 316 stainless steel swivel hoist ring with metric threads, providing a 360-degree swivel, 180-degree pivot lifting point for stainless and corrosion-sensitive applications. It is rated at 100% of its Working Load Limit at any sling angle down to 90 degrees.

Key Features

• All components 316 stainless steel (bolt retainers 15-7 PH magnetic stainless)
• Metric-thread bolt (M8 through M90 depending on frame size)
• Working Load Limit: 200 kg up to 22,300 kg by frame size
• Rated at 100% at 90-degree load angle; 360-degree swivel
• 316 stainless socket head cap screw bolt to ASTM F837M
• Individually proof tested to 2x WLL with certification
• Fatigue rated to 20,000 cycles at 1-1/2 times the WLL
• Silver color-coded washer identifies metric thread
• Product Identification Code (PIC) for material traceability
• 5:1 Design Factor

Common Applications

• Lifting points on metric-threaded equipment
• Corrosion-sensitive, washdown, marine and food-grade environments

Product Specifications

Every product includes Working Load Limit (WLL), manufacturer traceability code, and country of origin. For per-variant dimensions and detailed spec charts, see the Related Items tab (if this product has multiple sizes) or the Spec Sheet PDF linked in the Description tab.

Available on request

• Test certificate — proof-test certificate tied to manufacturer traceability code (rigging hardware, chain, wire rope; slings ship with a capacity tag).
• Mill certificate — raw material chemistry and mechanical properties (hardware / chain / wire rope only).
• DNV / ABS / NORSOK documentation for offshore or subsea applications.
• Custom configurations — non-standard lengths, colors, hardware combinations.

Email sales@slingcenter.com with your SKU or order number.

Standards & Compliance

Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.

Governing Standards

• ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
• ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
• ASME B30.10 — hooks
• OSHA 1910.184 and 1926.251 — general industry and construction sling safety
• WSTDA WS-2 and RS-1 — web and round sling design
• 49 CFR 393.102 to 393.130 — DOT cargo tie-down
• NACM — welded steel chain grade specs

Inspection & Safety

Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.

WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
