Specifications — Full Dimensions by Size
Type the load and we will highlight every size rated for it. Or click any row to pick that size.
This is below the 5:1 commonly specified for wire rope and synthetic sling systems (4:1 is standard for alloy chain components under ASME B30.9). Where a 5:1 column is shown it is SlingCenter’s derate — the manufacturer’s figure remains the rating of record.
Request datasheet
| Stock # | Size | WLL 4:1 (t) | WLL 5:1(t) SlingCenter derate | Weight (lb)(kg) | C (in)(mm) | D (in)(mm) | E (in)(mm) | F (in)(mm) |
|---|---|---|---|---|---|---|---|---|
| 772195 | 6" (152mm mm) | 1.81 | 1.45 | 9.94.5 | 3.5089 | 5.98152 | 5.51140 | 7.01178 |
| 772211 | 8" (203mm mm) | 2.27 | 1.82 | 24.311.0 | 4.88124 | 7.99203 | 6.73171 | 9.76248 |
| 772239 | 10" (254mm mm) | 2.72 | 2.18 | 31.514.3 | 6.38162 | 10.00254 | 7.76197 | 11.73298 |
| 772257 | 12" (305mm mm) | 3.63 | 2.9 | 60.027.2 | 7.24184 | 12.01305 | 5.98152 | 15.24387 |
| 2003424 | 14" (356mm mm) | 4.54 | 3.63 | 98.144.5 | 8.74222 | 14.02356 | 9.02229 | 17.99457 |
The 4:1 column is the manufacturer’s published Working Load Limit and is the rating of record — the figure marked on the product. The 5:1 column is calculated by SlingCenter as WLL × 4 ÷ 5, for comparison against components rated at the 5:1 commonly specified for wire rope and synthetic sling systems. It is always the lower of the two. We never restate a Working Load Limit upward. Size is the manufacturer’s nominal trade size and does not change between unit views — this part is ordered and stamped by that size in every market; the millimetre figure beside it is the equivalent, not a different size.
The Crosby S-601-S oil field snatch block is built specifically for the demanding conditions of oil field drilling and workover operations. Heavy-duty construction with sealed bearings and corrosion-resistant finish for extended service in harsh oilfield environments.
Key Features
- Purpose-built for oilfield operations
- Heavy-duty construction for harsh environments
- Sealed bearings resist dirt and moisture
- Snatch design for quick rope loading
Common Applications
- Oil field drilling operations
- Workover rig rigging
- Production platform line handling
Standards & Compliance
Manufactured by Crosby McKissick for oilfield service.
Safety & Standards
Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.
Governing Standards
- ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
- ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
- ASME B30.10 — hooks
- OSHA 1910.184 and 1926.251 — general industry and construction sling safety
- WSTDA WS-2 and RS-1 — web and round sling design
- 49 CFR 393.102 to 393.130 — DOT cargo tie-down
- NACM — welded steel chain grade specs
Inspection & Safety
Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.
WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
Order Sheet — 5 variants
Search below or click column headers to sort. Add any quantity per row to your cart.
| Option ▴▾ | SKU ▴▾ | Price ▴▾ | Weight ▴▾ | Stock | Qty | Add |
|---|---|---|---|---|---|---|
| BLK 601-S VERT 6 IN OL 2.00T 3/8 L | 772195 | $685.00 | 10.0 lb | ✓ In Stock | ||
| BLK 601-S VERT 8 IN OL 2.50T 1/2 L | 772211 | $1,362.00 | 20.0 lb | ✓ In Stock | ||
| BLK 601-S VERT 10 IN OL LP 3.00T 5/8 L | 772239 | $1,648.00 | 30.0 lb | ✓ In Stock | ||
| BLK 601-S VERT 12 IN OL LP 4.00T 3/4 L | 772257 | $2,888.00 | 60.0 lb | ✓ In Stock | ||
| BLK 601-S VERT 14 IN OL LP 5.00T 7/8 L | 2003424 | $3,626.00 | 98.0 lb | ✓ In Stock |
Weights are approximate shipping weights.
