Grade 100 — AMH / Cartec (Carcano, made in Italy) rotating lifting point. Powder-coated, load-rated and individually WLL-marked. Sold quote-only and drop-shipped. Dimensions in mm and WLL in metric tonnes (t) per the Cartec catalog; weights in lb. C815X – Rotating Weld-On Eyebolt with Ring, Grade 100, 4:1 design factor. Weld-on base for permanent attachment.
C815X – Rotating Eyebolt Weld-on Type w/Ring (Grade 100, 4:1 design factor)
| Part # | WLL (t) | A (mm) | B (mm) | C (mm) | E (mm) | H (mm) | D1 (mm) | S x 45° (mm) | Weight (lb) |
|---|---|---|---|---|---|---|---|---|---|
| C815X025 | 2.5 | 34 | 16 | 58 | 61 | 131 | 52 | 5.5 | 2.31 |
| C815X040 | 4 | 40 | 18 | 72 | 67 | 152 | 58 | 7 | 3.17 |
| C815X067 | 6.7 | 45 | 22 | 65 | 73 | 158 | 75 | 8.5 | 5.95 |
| C815X010 | 10 | 50 | 23 | 92 | 86 | 201 | 85 | 10 | 8.70 |
| C815X017 | 17 | 70 | 32 | 120 | 105 | 255 | 110 | 12 | 18.73 |
Safety & Standards
Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.
Governing Standards
- ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
- ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
- ASME B30.10 — hooks
- OSHA 1910.184 and 1926.251 — general industry and construction sling safety
- WSTDA WS-2 and RS-1 — web and round sling design
- 49 CFR 393.102 to 393.130 — DOT cargo tie-down
- NACM — welded steel chain grade specs
Inspection & Safety
Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.
WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
C815X – Rotating Eyebolt Weld-on Type w/Ring (Grade 100, 4:1 design factor)
| Part # | WLL (t) | A (mm) | B (mm) | C (mm) | E (mm) | H (mm) | D1 (mm) | S x 45° (mm) | Weight (lb) |
|---|---|---|---|---|---|---|---|---|---|
| C815X025 | 2.5 | 34 | 16 | 58 | 61 | 131 | 52 | 5.5 | 2.31 |
| C815X040 | 4 | 40 | 18 | 72 | 67 | 152 | 58 | 7 | 3.17 |
| C815X067 | 6.7 | 45 | 22 | 65 | 73 | 158 | 75 | 8.5 | 5.95 |
| C815X010 | 10 | 50 | 23 | 92 | 86 | 201 | 85 | 10 | 8.70 |
| C815X017 | 17 | 70 | 32 | 120 | 105 | 255 | 110 | 12 | 18.73 |
Order Sheet — 5 variants
Search below or click column headers to sort. Add any quantity per row to your cart.
| Option ▴▾ | SKU ▴▾ | Price ▴▾ | Stock | Qty | Add |
|---|---|---|---|---|---|
| C815X025 – 2.5 t | C815X025 | $0.00 | ✓ In Stock | ||
| C815X040 – 4 t | C815X040 | $0.00 | ✓ In Stock | ||
| C815X067 – 6.7 t | C815X067 | $0.00 | ✓ In Stock | ||
| C815X010 – 10 t | C815X010 | $0.00 | ✓ In Stock | ||
| C815X017 – 17 t | C815X017 | $0.00 | ✓ In Stock |
Bulk order? Email sales@slingcenter.com with your list — we'll build a single quote.
