AMH BCD-Series — Beam Clamp with Shackle
The AMH BCD beam clamp with a movable shackle is the easy way to install a rigging point on a structural beam — simple hand installation, no tools required. 1 to 10 ton capacity with a movable shackle rated for angled loading at 0° / 15° / 30° / 45°. Compact, portable, low-headroom “Theatrical Black” matte finish.
- Capacity range: 1 – 10 ton (reduced WLL as load angle from vertical increases)
- 5:1 design factor for use with powered or manual hoists
- The easy way to install a rigging point — simple installation by hand, no tools required
- Compact and portable low-headroom design
- Movable shackle — angle-rated 0–45°. For straight vertical hoist mounting, see the BC fixed beam clamp.
- “Theatrical Black” — all parts matte black
- Standards: OSHA, ASME B30, NASA-STD-8719.9, EU 2006/42/EC
Select capacity below; pricing by quote. BCD models carry reduced WLL as load angle from vertical increases.
Capacity & dimensions
AMH BCD-Series Beam Clamp with Shackle — Specifications & Dimensions
| Model | Capacity | WLL @0° (lb) | WLL @15° (lb) | WLL @30° (lb) | WLL @45° (lb) | A – flange range (in) | B max (in) | C (in) | D (in) | E (in) | F max (in) | H (in) | Weight (lb) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BCD-01 | 1t | 2,200 | 1,800 | 1,500 | 1,100 | 3.1-9.4 | 14.6 | 8.7 | 0.75 | 7.8 | 5.7 | 1.7 | 9 |
| BCD-02 | 2t | 4,400 | 3,700 | 2,900 | 2,200 | 3.1-9.4 | 14.6 | 8.7 | 0.75 | 7.8 | 5.7 | 1.7 | 11 |
| BCD-03 | 3t | 6,600 | 5,500 | 4,400 | 3,300 | 3.5-13.0 | 19.7 | 10.2 | 1.12 | 11 | 8.2 | 2.4 | 22.4 |
| BCD-05 | 5t | 11,000 | 9,100 | 7,300 | 5,500 | 3.5-13.0 | 19.7 | 10.2 | 1.41 | 11 | 8.2 | 2.4 | 26.2 |
| BCD-10 | 10t | 22,000 | 18,300 | 14,500 | 11,000 | 3.5-13.4 | 20.6 | 12 | 1.5 | 13 | 8.7 | 3.6 | 40.5 |
Safety & Standards
Every product we carry is individually marked with Working Load Limit (WLL), manufacturer traceability code, and country of origin. Inspection and mill certificates are available on request — email sales@slingcenter.com with your order number.
Governing Standards
- ASME B30.9 — slings (web, round, wire rope, chain) inspection and use
- ASME B30.26 — rigging hardware (shackles, eye bolts, links, turnbuckles)
- ASME B30.10 — hooks
- OSHA 1910.184 and 1926.251 — general industry and construction sling safety
- WSTDA WS-2 and RS-1 — web and round sling design
- 49 CFR 393.102 to 393.130 — DOT cargo tie-down
- NACM — welded steel chain grade specs
Inspection & Safety
Before every use: visual check for cracks, corrosion, distortion, wear, and illegible markings. Annually (minimum): documented periodic inspection by a trained inspector. Remove from service at first sign of damage. Never repair rigging hardware by welding, heating, or bending.
WARNING: Improper use of rigging can cause death or serious injury. Never exceed the rated Working Load Limit. Apply derating for side-loading, elevated temperature, or chemical exposure. Final application decisions must be made by a Qualified Person per OSHA 1926.32(m).
AMH BCD-Series Beam Clamp with Shackle — Specifications & Dimensions
| Model | Capacity | WLL @0° (lb) | WLL @15° (lb) | WLL @30° (lb) | WLL @45° (lb) | A – flange range (in) | B max (in) | C (in) | D (in) | E (in) | F max (in) | H (in) | Weight (lb) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BCD-01 | 1t | 2,200 | 1,800 | 1,500 | 1,100 | 3.1-9.4 | 14.6 | 8.7 | 0.75 | 7.8 | 5.7 | 1.7 | 9 |
| BCD-02 | 2t | 4,400 | 3,700 | 2,900 | 2,200 | 3.1-9.4 | 14.6 | 8.7 | 0.75 | 7.8 | 5.7 | 1.7 | 11 |
| BCD-03 | 3t | 6,600 | 5,500 | 4,400 | 3,300 | 3.5-13.0 | 19.7 | 10.2 | 1.12 | 11 | 8.2 | 2.4 | 22.4 |
| BCD-05 | 5t | 11,000 | 9,100 | 7,300 | 5,500 | 3.5-13.0 | 19.7 | 10.2 | 1.41 | 11 | 8.2 | 2.4 | 26.2 |
| BCD-10 | 10t | 22,000 | 18,300 | 14,500 | 11,000 | 3.5-13.4 | 20.6 | 12 | 1.5 | 13 | 8.7 | 3.6 | 40.5 |
Order Sheet — 5 variants
Search below or click column headers to sort. Add any quantity per row to your cart.
| Option ▴▾ | SKU ▴▾ | Price ▴▾ | Stock | Qty | Add |
|---|---|---|---|---|---|
| BCD-01 – 1t (2,200 lb) w/ shackle | BCD-01 | $0.00 | ✓ In Stock | ||
| BCD-02 – 2t (4,400 lb) w/ shackle | BCD-02 | $0.00 | ✓ In Stock | ||
| BCD-03 – 3t (6,600 lb) w/ shackle | BCD-03 | $0.00 | ✓ In Stock | ||
| BCD-05 – 5t (11,000 lb) w/ shackle | BCD-05 | $0.00 | ✓ In Stock | ||
| BCD-10 – 10t (22,000 lb) w/ shackle | BCD-10 | $0.00 | ✓ In Stock |
Bulk order? Email sales@slingcenter.com with your list — we'll build a single quote.
